What Causes Deterioration in Surface Roughness During Machining? A Guide to Prevention
"Surface roughness" is one of the key factors that determine product quality during machining. Many operators find it difficult to achieve the surface roughness specified in design drawings, or struggle with unexpected surface roughness that has no identifiable cause.
"I know I should adjust the feed rate, but I don't know how." "Changing tools didn't improve the situation." Issues like these directly impact production efficiency and costs.
This article provides an in-depth look at the primary causes of surface roughness deterioration during machining, along with a clear and practical guide to prevention, focusing on tool selection and cutting conditions.
Factors Causing Deterioration of Surface Roughness
Surface roughness refers to the minute irregularities on the surface of machined products. The primary causes of increasingly pronounced surface irregularities, or in other words the surface becoming rougher, can be broadly divided into two categories: cutting conditions and cutting tool wear.
Factor 1: Cutting Conditions
During machining, the tool cuts away material as it rotates or moves linearly. In theory, the tool's cutting edge invariably leaves behind a series of minute peaks along its path (cusp height).
Cusp height represents the theoretical surface roughness. In particular, higher feed rates widen the spacing between peaks, resulting in greater surface irregularities.
For example, when using a ball end mill for plane machining, doubling the feed rate worsens the theoretical surface roughness (height of surface irregularities) by approximately four times. When surface quality is a priority in finishing, the basic approach is to reduce the feed rate.
Additionally, excessive cutting depth or long tool overhang can lead to self-excited vibration, also known as "chatter vibration." This vibration transfers to the machined surface, producing scaly patterns and periodic surface irregularities, and significantly degrading surface roughness.
Factor 2: Cutting Tool Wear and Built-Up Edge
Even new tools inevitably experience edge wear as machining progresses. Tools with edge wear lose their sharpness, causing various adverse effects on the machined surface.
Also "Built-up edge" is a particular problem when machining soft materials such as aluminum or mild steel. This phenomenon occurs when the high temperature and pressure generated during machining cause some of the removed chips to adhere and build up on the cutting edge of the tool.
The built-up edge grows and breaks off repeatedly. Portions may detach and adhere to or gouge the machined surface, resulting in nicks and scratches. Because it destabilizes the cutting ability of the tool itself, built-up edge is a particularly troublesome factor in surface roughness deterioration.
In addition to built-up edge, flank wear and rake face wear (crater wear) can also dull the tool's cutting edge. As a result, cutting resistance increases, making the surface finish more prone to gouging and burrs, and leading to deteriorated surface roughness.
Issues Caused by Deteriorating Surface Roughness
When surface roughness deteriorates and exceeds the values specified in design drawings, it not only compromises appearance, it can also lead to serious issues affecting product functionality and reliability.
Poor Air and Oil Tightness
Surface irregularities are a fatal flaw in parts requiring air or oil tightness, such as sliding surfaces of cylinders and valves, and flange mating faces. Large irregularities can create gaps between parts, resulting in oil or air leakage.
It also increases frictional resistance in sliding parts, potentially causing premature wear or seizure of parts.
Loss of Metallic Luster
A beautiful metallic luster is an important factor in determining the quality of exterior and decorative parts of products.
High surface roughness and pronounced irregularities cause diffuse reflection of light, reducing the surface's natural gloss and giving it a dull appearance. This significantly reduces the added value of the product.
Lack of Machining Allowance, Leading to Machining Defects
A rough surface can also be described as a condition in which the part exhibits unstable dimensions.
For parts with strict dimensional tolerances, even if the measured "peaks" of surface irregularities fall within specified tolerance, the "valleys" may already lie below the lower tolerance limit. In such cases, additional machining (re-machining) to improve surface finish may leave no remaining material allowance (machining allowance), resulting in undersized, defective products.
A Guide to Improving Surface Roughness
To improve surface roughness, it is effective to approach the issue from two perspectives: "tool selection" and "cutting conditions." By considering these approaches comprehensively and finding the ideal conditions for your company's machining environment, you can achieve both high quality and productivity.
Solutions Using Tool Selection
Choosing the appropriate tool can sometimes resolve surface roughness issues at their source.
- Choose a Coating Tool (mainly for ferrous materials)
The main cause of built-up edge is the tendency for the workpiece to adhere to the tool. To prevent this, coating tools (mainly for ferrous materials) with special surface films are highly effective.
For example, coatings such as titanium nitride (TiN) and titanium aluminum nitride (TiAlN) reduce the coefficient of friction and enhance the adhesion resistance of the tool surface, significantly lowering the likelihood of built-up edge formation. - Select a Tool With a Large Rake Angle
The larger the rake angle of the tool, the sharper the cutting edge. Sharp edges reduce cutting resistance and enable smooth evacuation of chips, effectively preventing built-up edge formation and gouging.
Tools with large rake angles and sharp cutting edges are suitable for soft materials such as aluminum. - Choose a Wiper Insert
Wiper inserts dramatically improve finishing productivity and surface quality.
These inserts feature a specialized shape that includes a tiny, flat "wiper edge" alongside the standard corner radius. This wiper edge wipes the machined surface smooth, enabling faster feed rates at the same or even better surface roughness quality. This significantly reduces machining time and contributes to cost reductions.
Solutions Using Cutting Conditions
In addition to tool selection, solutions using cutting conditions are also essential.
- Reduce the Feed Rate
This is the most fundamental and reliable solution. As mentioned earlier, slowing the feed rate lowers the theoretical surface roughness (cusp height), resulting in a smoother surface finish.
However, it has the disadvantage of increasing machining time. - Increase the Rotational Speed (Increase the Cutting Speed)
Increasing the cutting speed can sometimes shift the machining area into a region where built-up edge is less likely to form.
Additionally, increasing rotational speed while keeping the table feed (mm/min) constant reduces the feed per tooth, resulting in a better surface finish. - Increase the Number of Teeth on the Tool
Even with the same table feed, increasing the number of tool teeth can lower the feed per tooth. This makes it possible to improve surface roughness without changing the machining time. - Cooling the Cutting Point
Proper coolant supply inhibits temperature rise at the cutting point and prevents built-up edge formation.
It also helps to evacuate chips smoothly, effectively preventing chips from re-adhering to the machined surface.
For more information on cutting speed, see the following article.
Conclusion
Improving surface roughness in machining is a crucial issue for enhancing product value. The main factors that cause this deterioration are "inconsistencies in cutting conditions” and "tool wear.”
To address this, it is important to first identify the causes of surface roughness deterioration in your company's machining. Then, the fastest way to improve the situation is to select a tool with the appropriate coating and shape, and to optimize cutting conditions such as feed rate and rotational speed.
Using the solutions introduced here as a reference, aim to set optimal cutting conditions while maintaining a balanced approach.
Author: Emi Baba
Editor: EGGO CO., LTD.
