CNC Tapping Center TC-31B

Discontinued Product

CNC Tapping Center TC-31B

Highly productive column traverse machine with high-end functions and a two-face table for high-speed and high-quality machining, in spite of its compact body

We ended sale of this product.
The information on the telephone about repair or maintenance of product should have a look here.

Information

A compact splash cover and a new single door are used to secure a large opening, enabling easy workpiece loading/unloading and automation.

Chip shower Chip shower pipes are located at the upper section inside the machine fot more effective chip removal.

A magazine with a capacity of 26 tools (one spindle) is used to respond to long machining composed of many jobs that use many tools and multiple products machining.

Brother's original 180-degree quick-turn table is standard equipped to enable non-stop operation with zero time-loss during workpiece loading and unloading. A line of multiple machines can easily be formed for automation or to save labor. A use of single machine is, of course, also possible.

Product Specification

item	TC-31B
Max. spindle speed	12,000min^‒1 16,000min^‒1
Travels	X:350mm Y:250mm Z:350mm
Tool storage capacity	26pcs.(＋1)
Rapid traverse rate (XYZ-area)	50m/min×50m/min×50m/min
Required floor space	1,404mm×3,204mm
