This is a video of aluminum machining performed on horizontal machining center SPEEDIO H550Xd1 with BT30 spindle. SPEEDIO H550Xd1 is a compact horizontal machining center with BT30 spindle. It has a wide jig area of ø600 mm and height of 580mm, enabling mounting of large and long workpieces. Equipped with the newly developed direct ATC 30-tool magazine that enables tool change time of 1.1 seconds for tool to tool, and the high acceleration/deceleration motor that enables spindle start/stop time of 0.15 seconds or less, it can achieve high productivity. The NC unit is equipped with Brother's latest control CNC-D00. It achieves lean operability that is optimal for manufacturing, contributing to increased work efficiency and operation rates at production sites.

This video shows high-speed machining of an impeller performed on vertical machining center SPEEDIO S500Xd1-5AX with BT30 spindle. It is a simultaneous 5-axis control machining. SPEEDIO S500Xd1-5AX is a high-productivity, high-accuracy BT30 spindle vertical machining center. This is the best-selling model of the SPEEDIO series, and can be used for a wide range of machining with a variety of spindle specifications and a wide range of magazine specifications. The newly developed 28-tool magazine further advances process-intensive machining. The NC unit is equipped with Brother's latest control CNC-D00. Optimized control through integrated mechanical and electrical development eliminates waste in all operations during machining and achieves high productivity. By achieving lean operability optimal for manufacturing, it contributes to work efficiency and operation rates improvement at production sites.

This video shows corner cutting performed on multi-task machine SPEEDIO M200Xd1-5AX with BT30 spindle. It is a simultaneous 5-axis control machining. SPEEDIO M200Xd1 is a BT30 spindle multi-task machine that advances process-intensive machining. Equipped with a tilting rotary table, a variety of processes can be integrated with one machine, from combined processing of turning and machining to multi-face machining. Additionally, the simultaneous 5-axis control function allows machining of complex shapes. The newly developed 28-tool ATC magazine further advances process-intensive machining. The NC unit is equipped with Brother's latest control CNC-D00. Optimized control through integrated mechanical and electrical development eliminates waste in all operations during machining and achieves high productivity. By achieving lean operability optimal for manufacturing, it contributes to work efficiency and operation rates improvement at production sites.
