SPEEDIO

W1000Xd2

W1000Xd2
  • W1000Xd2
  • W1000Xd2
  • W1000Xd2
  • W1000Xd2

Mounting a new 28-tool magazine promotes process integration for machining large workpieces.
With maximum table loading capacity increased to 500 kg and increased Z-axis travel, the machine is widely suitable for a variety of production systems.

W1000Xd2 Product introduction

W1000Xd2 Seminar video

video thumbnail
1.Description of Wide Travel Compact Machining Center
（3min39s）

video thumbnail
2.Features of W1000Xd2（14min58s）

video thumbnail
3.Case Study
（3min39s）

Product points

Machining Area

28-tool magazine, max. loading capacity of 500 kg, and increased Z-axis travel
Further improves applicability from large workpiece machining to multi-product small-volume production

Machining Area
Productivity

Untiring pursuit of high productivity
Reduction in waste by optimized control through machine/controller integrated development

Productivity
Machining Capability

With highly efficient spindle motor and highly rigid structure,
the machine is suitable for a broad range of machining

Machining Capability
Operability

Equipped with new “CNC-D00” controller for improved usability
Enhanced accessibility to make setup easier

Operability

Specifications

item W1000Xd2
Max. spindle speed 12,000min-1
10,000min-1 high-torque(Optional)
16,000min-1 (Optional)
Travels X:1,000mm Y:500mm Z:380mm
Tool storage capacity 14pcs./21pcs./28pcs.
Rapid traverse rate (XYZ-area) 50m/min × 50m/min × 56m/min
Required floor space 2,410mm × 2,233mm
BT dual contact spindle (BIG-PLUS) Optional
Coolant Through Spindle (CTS) Optional

Machining example

This new machine enables workpiece machining previously considered impossible in various industries, including the automobile industry.
